G06V 10/22

Definition

Diese Klassifikationsstelle umfasst:

(Für diese Definition ist die deutsche Übersetzung noch nicht abgeschlossen)

Guiding a pattern recognition process or device to a specific region of an image where the pattern recognition algorithm is to be applied, e.g. using fiducial markers.

The use of reference points in images, e.g. patterns having unique combinations of colours or other image properties, which make them useful for guiding a pattern recognition process.

Examples

Bildreferenz:G06V0010220000_0

A fiducial marker placed in the centre of an object is used for its object detection and recognition.

Bildreferenz:G06V0010220000_1

Bildreferenz:G06V0010220000_2

A pattern present on a marker gives additional information about the scene to be recognised.

Beziehungen zu anderen Klassifikationsstellen

Determination of position or orientation of image objects using fiducial markers is covered by group G06T 7/70.

Querverweise

Nichteinschränkende Querverweise in anwendungsorientierte Klassifikationsstellen

Devices for tracking or guiding surgical instruments	A61B 34/20
Fiducial marks and measuring scales in optical systems	G02B 27/32
Marks applied to semiconductor devices	H01L 23/544

Informative Querverweise

Aligning, centring, orientation detection or correction of the image	G06V 10/24
Image preprocessing for image or video recognition or understanding involving the determination of region of interest [ROI] or volume of interest [VOI]	G06V 10/25
Image analysis for determining position or orientation of objects or cameras	G06T 7/70

Glossar

AR	augmented reality
ARTag	fiducial marker system based on ARToolKit
ARToolKit	open-source software library for augmented reality
FFT	fast Fourier transform
fiducial marker fiducial markers	a fiducial marker is an image element which is explicitly designed for serving as a visual landmark point. A fiducial marker can be as simple as a set of lines forming crosshairs or a rectangle, but it can also be a more elaborate pattern such as an augmented reality tag, which additionally conveys information encoded as a two-dimensional barcode. Fiducial markers generally provide information about the position and, often, the orientation or the three-dimensional arrangement of objects in images. Additionally, they can comprise unique identifiers to support the recognition process. Fiducial markers are designed for being easily distinguishable from other image elements; therefore, they commonly have sharp image contrasts (e.g. by limiting their colours to black and white), and they are often designed to generate sharp peaks in the frequency space, allowing them to be easily recognisable by a two-dimensional Fourier transform. Commonly known fiducial markers are those defined by the augmented reality toolkit (ARToolKit).

G06V 10/22

Definition Statement

This place covers:

Guiding a pattern recognition process or device to a specific region of an image where the pattern recognition algorithm is to be applied, e.g. using fiducial markers.

The use of reference points in images, e.g. patterns having unique combinations of colours or other image properties, which make them useful for guiding a pattern recognition process.

Examples

Bildreferenz:G06V0010220000_0

A fiducial marker placed in the centre of an object is used for its object detection and recognition.

Bildreferenz:G06V0010220000_1

Bildreferenz:G06V0010220000_2

A pattern present on a marker gives additional information about the scene to be recognised.

Relationships with other classification places

Determination of position or orientation of image objects using fiducial markers is covered by group G06T 7/70.

References

Application-oriented references

Devices for tracking or guiding surgical instruments	A61B 34/20
Fiducial marks and measuring scales in optical systems	G02B 27/32
Marks applied to semiconductor devices	H01L 23/544

Informative references

Aligning, centring, orientation detection or correction of the image	G06V 10/24
Image preprocessing for image or video recognition or understanding involving the determination of region of interest [ROI] or volume of interest [VOI]	G06V 10/25
Image analysis for determining position or orientation of objects or cameras	G06T 7/70

Glossary

AR	augmented reality
ARTag	fiducial marker system based on ARToolKit
ARToolKit	open-source software library for augmented reality
FFT	fast Fourier transform
fiducial marker fiducial markers	a fiducial marker is an image element which is explicitly designed for serving as a visual landmark point. A fiducial marker can be as simple as a set of lines forming crosshairs or a rectangle, but it can also be a more elaborate pattern such as an augmented reality tag, which additionally conveys information encoded as a two-dimensional barcode. Fiducial markers generally provide information about the position and, often, the orientation or the three-dimensional arrangement of objects in images. Additionally, they can comprise unique identifiers to support the recognition process. Fiducial markers are designed for being easily distinguishable from other image elements; therefore, they commonly have sharp image contrasts (e.g. by limiting their colours to black and white), and they are often designed to generate sharp peaks in the frequency space, allowing them to be easily recognisable by a two-dimensional Fourier transform. Commonly known fiducial markers are those defined by the augmented reality toolkit (ARToolKit).
