F16D 3/2237

Definition

Diese Klassifikationsstelle umfasst:

Gelenkkupplungen, bei denen die Rollglieder in Rillen beider Kupplungshälften geführt sind. Dabei sind beide Rillen im Schnitt aus Radien und Geraden zusammengesetzt, siehe die Rollbahnen (11b) und (12b) in der Figur.

Bildreferenz:F16D0003223700_0



F16D 3/2237

Definition Statement

This place covers:

Universal joints where the rolling members are being guided in grooves on both coupling parts. In the projection these grooves are composed of radii and straight lines, see groove line (11b) and (12b) in the figure.

Bildreferenz:F16D0003223700_0
